- 32-bit ARM CPU
- LAN Ethernet: 10/100Mbps; Protection: Built-2KV electromagnetic isolation;
- Serial TTL × 1: TXD, RXD, GND;
- Serial rate: Baud rate: from 300 to 256kbps can be set up to 3Mbps;
- Network Protocol: ETHERNET, ARP, IP, UDP, TCP;
- Tools: Module configuration software, TCP / UDP test tools, serial debugging software;
- Configurations: serial / network, free software packages.
- Power supply: DC 4.8 ~ 5.4V
- Mechanical parameters: Module Size (L × W × H): 55 × 23 × 20 (mm) with network isolation transformer and pins
- PCB Size (L × W): 40 × 23 (mm)
- Operating temperature: Industrial grade: -25 ~ 75 ° C.
- Preservation of the environment: -40 ~ 85 ° C, 5 ~ 95% RH.
|
